Dear Friends and Customers,

The VGMPlayer could play IMF Music files.

I'm working to support IMF music files on the VGMPlayer.

It's almost done and playing IMF songs now.

Please download the VGM Player again and You can have an updated version.
(You can find the location my email, I sent the information when you purchase the card)

What is IMF file and useful tools...

https://k1n9duk3.shikadi.net/imftools.html

SD Music Deluxe card has an OPL3 sound chip and the IMF files are also possible to play on APPLE II.

Hence, I researched the IMF file type and could make it run on SD Music Deluxe.

I searched for some good file formats that could work on APPLE II without any heavy CPU load.

In my thought the Music playing in APPLE II wouldn't be a problem but, when I apply the VGM songs in APPLE II,

It won't fit for games on APPLE II. so other file types are needed.

I can make my own format but, it isn't a good idea cause I can't make good songs...

So need another format it could be made by some of the composers and if possible to convert to a specified music format, it would be a nice.

I considered it an easy one and I found DRO and IMF files. Some of the files are based on MIDI format and have instrument data in to and need more consideration for APPLE II.

DRO vs IMF...

DRO file can extract DOSBOX program and good for OPL2/OPL3

IMF file can extract some DOS games and only for OPL2(OPL3 can)

And IMF file was simper to DRO and I did for it.

VGM Player would be a good player for VGM and IMF music files.

Background MUSIC(Sound) player on APPLE II

There are Mockingboard programs that can play in the background.

I also considering making a similar program that plays IMF sound files.

it would be helpful for the user's program.

Users could insert their own sound effects while background music playing.

Hope to complete it soon.

Thanks

Ian Kim

** VGM Player updated to V1.24

In this version, It supports large IMF files and has no file size limitation.

And hidden reading applied so you can play IMF songs seamlessly.

Enjoy more OPL2 music on SD Music Deluxe card.

Thank you

Ian

Dear friends and customers,

Firmware for SD DISK][ Plus has been newly updated.

Now, Also working well on the Lemmings game program.

In this version, internal improvements have been made to better support the DISK COPY program.
Below marked OK DISK COPY programs work well.

The above programs are disk-related utilities that are mainly used.

You can easily make a NIB file created after copying it, to archive or distribute it on the Internet.

However, the negative symptom was found

Some NIB images read very slowly.

it comes due to different virtual DISK spinning.

In this case,

Use a DISK Copy Program(such as 'COPY ][ PLUS 5.1' ) and copy the DISK to self.
In other words, Overwrite the Image by copy to DISK B --> DISK B

How to update firmware!
Put the this SDBIOS.ROM file in the root of the SD memory,
Then proceed with the firmware update on boot menu.

Thanks

Ian Kim

Dear friends and customers,

PT3 Player for APPLE II (Mockingboard).

https://www.youtube.com/watch?v=bdAxNCj_s6I&ab_channel=deater78

This is a working PT3 Player on the SD Music Deluxe card.

I patch the original program.

Please download it and enjoy PT3 music on your SD Music Deluxe.

Thanks a lot

Ian Kim

Dear APPLE II soft developers,

Please refer to this guide to control SD Music deluxe as the Mockingboard.

It would help on your program.

If you have any questions, please let me know.

Regards;

Ian Kim

Dear Friends and cumstomers,

The new game Lemming for APPLE //e was announced as under.

http://www.deater.net/weave/vmwprod/lemm/

I tested it on SD Music Deluxe and it had malfunctioned.

So, I dig it and finally can make it works.

Please download and enjoy it on your APPLE //e with SD Music Deluxe.

Thanks a lot.

Ian Kim

Dear friends and customers,

I'm glad to announce new firmware for the SD Music Deluxe card.

Please download and update your card.

It is only for the SD Music Deluxe card.

Version 1.0c ; For Better Mockingboard emulation.

Works fine on PETSCII Robots for Apple ][

Works fine on NOX ARECHAIST

And Some more..

----------------------------------------------------------------------------------------

How to update;

0) Power OFF your APPLE II

1) Your SD Music DLX card must be in SLOT #4

2) Remove Switch block(Firmware update mode) on SD Music DLX card.

3) Boot with SDMDV10C.NIB

4) Follow the Screen

5) Power OFF and Return the Switch block into SD Music DLX card (Default Right(Auto))

----------------------------------------------------------------------------------------

If you have any concerns, please let me know.

Thanks a lot

Ian Kim

Dear customers,

Thanks for your purchase of the APMSX card.

I added a VDP testing program in APMSX.HDV and User's manual also updated as followed.

If you are interested in VDP control by 65C02, Please refer to it.

Thanks a lot;

Ian Kim

Dear customers,

SD DISK ][ Plus firmware upgraded to V2.74p

- Applied New dial type
New dial only has 1/2 click and users need to change the type of dial.

How to change dial type;
'Press Dial + Power ON APPLE II'
If you hear a beep on APPLE II then release it.

It will change 1/1 type <--> 1/2 type

- And other minor changes applied.

How to update

Please refer to this excellent slide show (Thanks Mr. Johnson Lam)
http://www.youtube.com/watch?v=m-aRxqWuBzc

My friend found a nice WIFI SD Module as above.

With this Device, User can access SD memory card data on a WIFI Drive connection as the below.

So Copy, Move, Modify and create folders are all easy to manage files on SD memory card.

I think that it is the easiest way to access the SD memory chip via WIFI.

To configure the card, you need to refer here.

https://github.com/FYSETC/FYSETC-SD-WIFI

Thanks and enjoy your APPLE II

Ian Kim

Dear friends and customers,

I am glad to announce another multi-functioning accelerator for APPLE II.

It could provide a good capability on APPLE II system with faster BASIC speed, better memory and DHGR acceleration.

I spent some months to design and testing it and now want to receive orders from international buyers.

In fact, some month ago I already completed design and sold it several cards for local friends.

but, It took long time for international customers.
I don't have much good eyes now and then every month feel a little different and this card has very small parts and hard to make by hand. New card developing is hard for me.

Spending time and ideas on the new card.. is not just developing... it is exploring the APPLE II system.

When I built new devices, i really wanted to make them different than presents others.
I want to assign unique characteristics for my card and then there could be some special functions with it.
When I considered new features into my products, it doesn't complete easy, always brings other technical issues.
Maybe I still don't understand some of WOZ machine properly....

I don't know how long could I design and make cards for friends....

I had rest some weeks and feel much better now..   so you can give me order to make yours now.

The A2 OverDrive has several funny functions.
One is Digital output.. and we can play WAV songs with it (Of cause,  It need a DA converter)

High speed acceleration doesn't give other than the speed...
But, It bring the possibility for your APPLE II.
Faster running software will make other possibility for a real-time-based games..
On the graphics, it could provide smoother faster more object can move at one time period.
But, all software functions... not hard ware additions.. at least still now the accelerator card was as this.

For A2 OverDrive have hardware special functions.

1) interrupt generator
It provide IRQ or NMI interval timer interrupt. user can define the timing of interrupt.
Hope to be used for multi processing and for event processing.

2)Slot memory
Sold memory area $C100-C7FF which are reserved for ROM on SLOT peripherals.
A2 Overdrive has ability to override this area to own RAM location.
Hence the area can use for User's area ROM or RAM.
Also $C800-CFF0 area also can override it to own RAM.
It is one of my philosophy that if technically possible then try to make new&fun functions.

3) Digital I/O
Many of people wouldn't use it except sound module function to play the WAV (sampling) sound.
I provide it for H/W fun.
8bits Input and 16bit output.

Other small functions such as fixed interval reader, R/W memory speed adjust etc...
Some are provided setup value due to limitation on APPLE II to co-operate it but, others are for special functions those couldn't find other accelerators.

I'm making the English manual for this card and some are completed but, when you order and receive the card, you can have proper manual.

Other information are scattered on this site. just consider it as an  hide and seek game.

Please order this card for an engineer who want to make more fun devices for APPLE II.

https://drive.google.com/file/d/1ngjR27VpbYu-5Wcg0mP1yrwwpku0yMQF/view?usp=sharing
This is only for the Introduction.

Full users manual would be provided for buyers only.

*RAM works Memory size is 384KB

*8bit Input port now.

https://youtu.be/CvvzKiOJkkA

https://youtu.be/jENz3w-1TC4

Specification

• MAX 16Mhz accelerator card for Apple //e  and Some revision of APPLE ][+ are works

• Integrated Memory emulation of Saturn (64KB) and RAMWORKS (384KB)

• Two 8bits Digital Output ports

• One 8bits Digital Input port

• Integrated programmable Interrupts generator

• Additional Virtual SLOT RAM on $C100-$CFFE

Acceleration

• A2 OverDrive 65C02 CPU works up to 16Mhz

• Accelerate Main and AUX area

– Accelerates ROM ($D000-$FFFF) and Hi-RAM($D000-$FFFF)

– Accelerates Saturn 64KB and RAMWORSK 384KB

– Accelerates BASIC programs

– Accelerates DHGR and DGR programs

• CPU speed can set to 16Mhz, 7.16Mhz, 3.58Mhz and 1Mhz

*** Parts shortage(Parts price is too expensive now)

I think we are really experiencing serious problems.

I'm using CPLD for this card and the parts price became 4 times.

And I can't make it with the price so, I stop selling it.

But, If you are still interested, please ask me for the price.

Sorry for this.

** Shipping issues

Due to Covid19, only some country covered with the standard shipping costs for shipping.

Please refer to the below and please ask for the shipping costs if your country is not in the list.

In this case, I have to send the package with EMS or for the UPS (Higher costs).

Sorry for it.

Standard Shipping only

Thank you very much

Ian Kim

SD MIDI ][+ Player Version 0.2K

Supports MIDI System exclusive.

Much better on Hidden DISK Reading.

Thank you.

Demo version Download link

https://quick09.tistory.com/1510

--------------------------------------------------------

TESTED

MIDI card

SD MIDI][+ Card

With DISK Emulator

SD DISK][ Emulator

SD DISK][ plus

CFFA 3000

Compatible System

APPLE ][+ 64K(No extra font)

APPLE //e 64KB and 128KB

APPLE IIgs ROM0 (Normal speed and Fast speed)

--------------------------------------------------------

I'm using SD MIDI ][+ Player while on my resting time.

From this version it supports MIDI system exclusive.

System Exclusive is depend on the MIDI sound module but, the default given module accepting and play better. Sound became smoother..

I think that I've done almost of all for MIDI player.

And I need to finalize this version. just left full testing.

Thanks a lot

Ian Kim

Dear Friends and customers,

SD MIDI][+ Player using three timers of SD MIDI ][+ card.

And I had a report from a user who having some tempo issue.

Please patch your SD MIDI ][+ card as the photo.

It required 3 resistors (4.7K - 10K  is good enough).

And solder the resistors as the below.

This Location pins are not used but, it receipt some noise.

And the Resistors will pull down the pins and set it stable.

Thanks a lot

Ian Kim

Dear Customers and Friends,

SD MIDI ][+ Player Version 0.2H

It has enhanced Hidden Reading.

System and device Requirments

1) Mininum 64KB APPLE ][

Works and tested on APPLE ][+, APPLE //e and APPLE IIgs

2) HDD Emulator, SD DISK II or others are recommended.

FDD also works but, will have delay if song file is larger than 24KB

3) SD MIDI ][+ card or the Passport compatible MIDI card must in SLOT#2.

* Standard licensed version has no limit of MIDI file size.

* Only MIDI format 0 support. Other format of MIDI song have to converted MIDI 0 format.

   Please visit here for converter https://www.anvilstudio.com/

-----------For other Passport compatible MIDI card owners-----------

Please order the licensed version and send email to me.

* DEMO Version (It only can play upto 12KB MIDI file).

Unzip it and copy the MIDIDEMO.HDV to your HDD Emulator.

To use MIDI Player,

1) Passport compatible MIDI card must in SLOT#2

2) HDD emulator required

3) Min 64KB memory of APPLE II

** To SD MIDI][+ Owners **

Please email me for your license.

What is the SD MIDI ][+

https://quick09.tistory.com/1347

Thanks a lot

Ian Kim

Dear customers and Friends,

SD MIDI II+ Player did update for more functions and accurate play.

In this version, It used a Hidden reading method when it need more data from Disk and results having seamless polaying.

And user can select own Level meter char. by pressing 'B' and 'N' on APPLE II.

Playing tempo tuned more accurate.

Just have a time to watch how it's playing as under.

https://youtu.be/3qIji9rbLL0

Thanks a lot

Ian Kim.

Dear Friends and Customers,

This version optimized some more for the Level meter and added on left as a channel indicator(?).

And level meter speed was incresed and good now.

It is the best what I can do with 1Mhz 6502 APPLE II.

Just watch the video.

Thanks a lot.

What is the SD MIDI ][+ ?

https://quick09.tistory.com/1347

It isn't a freeware, I will provide for SD MIDI ][+ buyers for free.

It would be announced when It finished.

Thanks a lot;

Ian Kim

Dear Friends and customers,

It's up to what I've been working on recently.
The biggest change in this version is the player used as far as the hardware supports it.
It support a progressive bar (level meta).
It is very tight to support this in the 1Mhz APPLE II.
It was made using even the hardware timer and interrupt supported by the SD MIDI II card.
It is quite difficult to support it.
After a lot of trial and error, I finally decided to use a timer interrupt for simultaneous processing.

For reference, these progressive bars are the 16 channels of MIDI, from 0 to 15 from the top.
It seems that it is too difficult to handle this with interrupts in Apple2.
It's so hard that I don't want to bother you anymore.

It works fine with or without an accelerator card but, If you use an accelerator card, the CPU load is reduced, so the tempo of the sound can come out a little more naturally. This is because the load on the interrupt side is large.

Since you have to use PRODOS, you can't completely push the IRQ routine away, so this is the best what I can do.
If I increase the speed of the progressive bar quickly, the CPU load increases, so this is the last choice.

it is a thankful result with APPLE II.

Now I have waht I wanted.

Please enjoy listening.

https://youtu.be/kf90YvsiFVc

** Some more information **

- MIDI file format 0 is supported. Other formats can be played smoothly by converting them to MIDI 0.
- There is no MIDI file size limit. However, if the file is large, a slight delay may occur. This is sometimes canceled by the internal timer when a delay occurs, but in some cases, it cannot be canceled and may exist as a sound delay.

It isn't a freeware sorry bout it but, I will provide SD MIDI][+ customers for free.

Thank you

Ian Kim

Dear friends and customer,

I'm making MIDI Player for SD MIDI ][+ card.

I have good progess as under.

https://youtu.be/ZTlHt_2uXoQ

MIDI Player works on APPLE //e and APPLE ][+(64KB).

It isn't a freewarwe but, I will provide SD MIDI][+ buyers without charge.

Enjoy MIDI music on our APPLE II with SD MIDI ][+.

Thank you!

Ian Kim

Dear Friends and customers,

I'm trying to make a MIDI Player for SD MIDI ][+ card.

It is just a testing by BASIC to check it it works .

https://youtu.be/wNLzpdOJ5Uk

After complete, I will provide it for SD MIDI ][+ buyers for free.

Thanks for your buying of SD MIDI ][+ card.

Ian Kim
